VDO OIL SYMBOL GAUGE PRESS BOOST MECH 1
கடைசியாக புதுப்பிக்கப்பட்டது
விலை:
R.F.Q
VDO Part No.: 150 194
Diameter: 2 1/16 in
Diameter (Metric): 52mm
Dial Scale: Single
Input Type: Mechanical
Connection: 1/8-27 NPT
Mounting Hardware: U-Bracket
Voltage: 12V
Bezel: Black, Rectangular Version
Lens: Nonreflective
Deflector: Black
Dial: Backlighting
Dialgraphics: Black Background with White Characters
Pointer: Translucent Backlighting, Red
Housing: Steel, Zinc-Plated and Chromatized
Mounting: Bracket, Steel, Zinc-Plated and Chromatized
Illumination: Clear
Variable: Green or Red Colour Cap
Connections: Blade Terminals 6.3 x 0.8mm
Fitting: M12 x 1.5
Share Product:
விவரம்
TECHNICAL DATA:
Operating Temperature: -30°C to +85°C
Protection: IP64 DIN 40050 from the front
Nominal Position: NL 0 to NL 90, DIN 16257
Vibration Resistance: 1g eff. max., 25Hz to 2000Hz duration 8h, f: 1 octave/min
Indication Accuracy: ±4% of the full range for the last 2/3 of the scale
Light Bulb: 12V 2W or 24V 2W (option)
விவரக்குறிப்பு
| திறவுச்சொல் | |
| பிராண்ட் | |
| தோற்றம் | US |
